Equal angle in two wall thicknesses and unequal angle in two sizes.
Section profile. All dimensions in mm.
| Section no. | A (mm) | T (mm) | Weight range (kg per 12 ft) |
|---|---|---|---|
| 3202 | 25.00 | 1.50 | 0.700 – 0.800 |
| 3203 | 25.00 | 2.80 | 1.300 – 1.500 |
A = overall dimension. T = wall thickness. Weight range is for one 12 ft (3.66 m) length.
Enquire About This SectionSection profile. All dimensions in mm.
| Section no. | A (mm) | B (mm) | T (mm) | Weight range (kg per 12 ft) |
|---|---|---|---|---|
| 3106 | 38.10 | 25.40 | 2.15 | 1.400 – 1.600 |
| 3111 | 50.80 | 25.40 | 2.85 | 2.000 – 2.200 |
A, B = overall dimensions. T = wall thickness. Weight range is for one 12 ft (3.66 m) length.
Enquire About This SectionQuote the section number and wall thickness from the product page, or describe what you need. We reply with weight, availability and a delivery date.
