Sections for casement (openable) windows. The 34 series covers the outer frame, shutter frame, mullion and clip. The 40 series adds a heavier outer frame.
Section profile. All dimensions in mm.
34 series
| Section no. | T (mm) | Weight range (kg per 12 ft) |
|---|---|---|
| 1301 | 1.50 | 1.650 – 1.900 |
T = wall thickness. Other dimensions as shown on the drawing, in mm. Weight range is for one 12 ft (3.66 m) length.
Enquire About This SectionSection profile. All dimensions in mm.
34 series
| Section no. | T (mm) | Weight range (kg per 12 ft) |
|---|---|---|
| 1305 | 1.50 | 1.350 – 1.600 |
T = wall thickness. Other dimensions as shown on the drawing, in mm. Weight range is for one 12 ft (3.66 m) length.
Enquire About This SectionSection profile. All dimensions in mm.
34 series
| Section no. | T (mm) | Weight range (kg per 12 ft) |
|---|---|---|
| 1310 | 1.50 | 2.400 – 2.600 |
T = wall thickness. Other dimensions as shown on the drawing, in mm. Weight range is for one 12 ft (3.66 m) length.
Enquire About This SectionSection profile. All dimensions in mm.
34 series
| Section no. | T (mm) | Weight range (kg per 12 ft) |
|---|---|---|
| 1315 | 0.85 | 0.480 – 0.550 |
T = wall thickness. Other dimensions as shown on the drawing, in mm. Weight range is for one 12 ft (3.66 m) length.
Enquire About This SectionSection profile. All dimensions in mm.
40 series
| Section no. | T (mm) | Weight range (kg per 12 ft) |
|---|---|---|
| 1321 | 2.30 | 2.100 – 2.300 |
T = wall thickness. Other dimensions as shown on the drawing, in mm. Weight range is for one 12 ft (3.66 m) length.
Enquire About This SectionQuote the section number and wall thickness from the product page, or describe what you need. We reply with weight, availability and a delivery date.
