Two curtain wall framing sections, 1423 and 1426, each drawn with its overall dimensions on the section page.
Section profile. All dimensions in mm.
| Section no. | T (mm) | Weight range (kg per 12 ft) |
|---|---|---|
| 1423 | 2.00 | 4.500 – 4.700 |
T = wall thickness. Other dimensions as shown on the drawing, in mm. Weight range is for one 12 ft (3.66 m) length.
Enquire About This SectionSection profile. All dimensions in mm.
| Section no. | T (mm) | Weight range (kg per 12 ft) |
|---|---|---|
| 1426 | 1.50 | 4.100 – 4.300 |
T = wall thickness. Other dimensions as shown on the drawing, in mm. Weight range is for one 12 ft (3.66 m) length.
Enquire About This SectionQuote the section number and wall thickness from the product page, or describe what you need. We reply with weight, availability and a delivery date.
